KATANA

KATANA

Applications

Live events and theatrical performances
Perfect for creating engaging atmospheres thanks to dynamic beams, precise pixel control, and vivid colors that enhance live shows.

TV studios and broadcast environments
Delivers excellent color rendering with adjustable color temperature, ideal for professional high-definition filming.

Indoor artistic installations
Features motorized zoom and a wide color range to create impactful scenic effects in exhibition spaces and creative setups.

Clubs and discos
Handles fast-paced environments with rapid movements and immersive light effects that amplify the energy of the venue.

Trade shows and temporary setups
A versatile solution for precise accent lighting, easily configurable even in setups with tight installation schedules.

Technical data

OUTPUT
12 x 20 W Full Color (RGBW) LEDs
Pixel to pixel control
Lumen source: 9600 lm

OPTICAL GROUP
Linear motorized zoom 3.5° (‘blade’ mode) – 30°

COLOR GENERATION
16 million colors
Wide palette of pure uniform whites with variable linear color temperature (2700 K – 8000 K)

CONTROL
Multi-function 4-digit 7-segment LED display + 4 soft keys
Controlled via DMX 512 and RDM standard digital communication protocols
Firmware updatable via DTS firmware uploader dongle

DMX
24 DMX channels (default)
64 DMX channels
16 DMX channels

TILT
Motorized Tilt 184°;
16-bit movement resolution

POWER SUPPLY
Electronic Wide-range 100-240 Vac 50/60 Hz;
Power consumption: 300 W max
Power Factor: PF >0.95

CONNECTIONS
Power supply: PowerCON TRUE1 In/Out panel connectors
DMX: XLR 5-pole In/Out panel connectors

CIRCUITS PROTECTIONS
Overvoltage and overtemperature circuits protection

TEMPERATURE
Operating: -10° +40° C

PHYSICAL
Finishing: Black
Weight: 19.5 Kg (43 lbs)
IP rating: IP20

TEST AND CERTIFICATION
CE

ACCESSORIES INCLUDED
1 x PowerCON TRUE1 female cable connector (code 0520P066)
1 x PowerCON TRUE1 male cable connector (code 0520P067)
1 x XLR 5 pins female cable connector (code 0508B147)
1 x XLR 5 pins male cable connector (code 0508B148)
2 x Omega bracket with “Fast Lock” connection 1/4 turn (code 02K00467)
2 x Bracket for ground installation with handles and rubber feet – already mounted on the unit (code 02SK0296)

ACCESSORIES ON REQUEST
Flightcase for 3 units (code 0521C066)
Aliscaf clamp for tube diameter 48-51 mm – max. load. 200 Kg (code 0521A033)
G-QUICK clamp Professional – max. load 100 Kg (code 0521A037)
Safety cable – 3 x 600 mm – max. capacity load 30 Kg (code 0521A010)
DTS firmware uploader dongle (code 03.LA.206)
